Overview
BloApCo Trim Cutters are engineered to solve one of the most persistent challenges in web manufacturing and converting operations: continuous edge trim and matrix scrap buildup. Installed as part of a larger trim removal system, these cutters reduce edge trim into small, manageable pieces that can be pneumatically conveyed through ductwork without causing clogs or blockages. This streamlined process reduces downtime, allows converting lines to operate at full speed, and supports cleaner, more efficient scrap handling.
Whether used under a corrugator, near a slitter, or integrated into a broader pneumatic scrap removal system, BloApCo Trim Cutters eliminate costly interruptions by ensuring edge trim is processed and removed in real time.
Product Details
BloApCo Trim Cutters are used in a wide range of industries, including converting, paper, plastic, film, non-wovens, and foil manufacturing. They are designed to handle materials ranging from ultra-thin films as light as 0.000025 inches to heavy fiberboard and laminated kraft materials up to 0.025 inches thick.
These cutters are categorized by duty level based on the material thickness and strength.
Light-Duty Models (for <1 mil / 25.4µm materials)
Ideal for light paper, poly films, Mylar, non-wovens, and recording tape. Some models can handle film as thin as 0.000025 in. (6.35 µm).
-
Model 7-6: 1 hp motor, 3,600 rpm, 7.75 in. inlet width, 1,000 cfm
-
Model 7-7: 1 hp motor, 2,000 rpm, 7 in. inlet width, 1,000 cfm
-
Model 8-5: 5 hp motor, 3,600 rpm, 13.5 in. inlet width, 4,500 cfm
Medium-Duty Models (for 3-20 mil / 76-508µm materials)
Suited for paper, light fiberboard, corrugated board, plastic film, foil laminates, and pressure-sensitive stock.
-
Model 3B: .75 hp motor, 2,000 rpm, 6.25 in. inlet width, 1,000 cfm
-
Model 5TOB / 5SC: 2 hp motor, 2,000 rpm, 8.5 in. inlet width, 3,000 cfm
-
Model 7-6 / 7-7 / 8-3 / 8-5: Also fall into medium-duty depending on material and setup
Heavy-Duty Models (for >20 mil / 508µm materials)
Engineered for solid bleached sulfate board, laminated kraft, and heavier non-ferrous materials up to 0.025 in. thick.
-
Model 5TOB / 5SC: Shared with medium-duty but used here for heavier material
-
Model 8-3: 5 hp motor, 2,000 rpm, 13.5 in. inlet width, 4,500 cfm
